Description
Air Bags B20 MOA Twin Bellow (Single Port) Dual Pack, Pair
Classic Aircooled VW Shocks and Bags parts by Limebug
The MOA B20 Air Bag, features a maximum restrained pressure exceeding all on the market still holding at 600PSI, sidewall holding at below 7″ operating pressure.
The Ultra Strong construction will maintain a narrow expansion body at all operating pressures. Webbed internal and external construction featuring a square sidewall. The rubber compound is over 4x thickness of equivalent dimension air bags. This bag is often used for A-frame custom contructions, heavy lift applications and load level.
Safe cycling upto 250PSI.
| Pressure (Bar) | 1 | 3 | 5 | 7 |
|---|
| External Diameter | 158.2mm | 162.3mm | 165.5mm | 168.5mm |
| Load (KN) | 1.604 | 4.120 | 6.720 | 9.380 |
Details:
- Maximum Extended Height: 10.6″
- Compressed Height: 2.8″
- Maximum Diameter: 7″
- Maximum Load at 100 PSI: 2,108 lbs.
- Port Size: 1/2″
- Top Fastener: 3/8″–16
- Bottom Fastener: 3/8″–16
- Mounting Hole Center: 1.75″ – Top/Center/Bottom
SKU: 030010144
Air Bags B20 MOA Twin Bellow (Single Port) Dual Pack, Pair
£154.00inc 20% VAT
The MOA B20 Air Bag, features a maximum restrained pressure exceeding all on the market still holding at 600PSI, sidewall holding at below 7″ operating pressure.
Description
Air Bags B20 MOA Twin Bellow (Single Port) Dual Pack, Pair
Classic Aircooled VW Shocks and Bags parts by Limebug
The MOA B20 Air Bag, features a maximum restrained pressure exceeding all on the market still holding at 600PSI, sidewall holding at below 7″ operating pressure.
The Ultra Strong construction will maintain a narrow expansion body at all operating pressures. Webbed internal and external construction featuring a square sidewall. The rubber compound is over 4x thickness of equivalent dimension air bags. This bag is often used for A-frame custom contructions, heavy lift applications and load level.
Safe cycling upto 250PSI.
Details:
SKU: 030010144
