Throughout the production years of Swing Axle rear suspension Beetles, there has been 3 iterations of Swing Axle length. Misidentifying your axle setup could mean your new wheels won’t fit or your tyres may rub on the inner arches – both are not ideal! With this little walkthrough we will show you the measurements and […]
No More Cutting CornersBolt-On Air Suspension for T2B For many years now, there hasn’t been a Bolt-On solution for Air Suspension for the Bay Window platform. To complete an Air Installation, owners have had to weld on Brackets to the rear axles, eliminating any chance of restoring their Bus back to standard. Using original fixings […]
The Bodywork Choosing a Colour Palette Starting its life over in the States back in the Early 60’s as a LHD Push Button Dash Razor, the once-looked after Type34 was a must-have, when it came up for sale. Back in 2021, we sent our 1964 Razor shell down to the guys at DC Customs, for […]
Trailing Arm Installation Guide For Limebug Bearing Beams
The History From bodge jobs to full-on fails; many tinkered with Type 1 vehicles are still operating on out-dated Front Axle designs. Although for years now, aftermarket retailers have sold weld-in adjuster kits to raise/lower your Beam, without precision cutting and welding these kits have never been a good solution. From twisted Beams to […]
Engine CCYear Variations + Calculations Engine Numbers, 1200-1600cc Engine Size Engine Code Single or Twin Port Year Power (BHP) 1200 D Single Port 8/65> 34 1300 F Single Port 8/65-7/70 40 1300 AB Twin Port 8/70-7/73 40 1300 AR Twin Port 8/73-7/75 44 1500 H Single Port 8/65-7/70 47 1600 AD Twin Port 8/70/7/73 50 […]
Dickies 1969 Razor Edge Limebug-Equiped Type 34 Oozing with class and style, Dickies Razor has rapidly gained popularity in the UK Aircooled scene. Originally being shown off at the prestigious Volksworld Show in 2021, many showed their appreciation of the build, labelling it ‘the coolest razor i’ve ever seen in my life’. Dickie followed on […]
The Performance Highly prone to belt slip/lift at high RPMs, OEM Pulley Systems can often be more stress than it’s worth. From loud engines to little cooling, the factory design is not meant for 21st Century stop-start traffic. For those looking for either an upgrade in performance and/or aesthetics on their vehicle, we can help […]
Alex’s 1975 BeetleLimebug-Equiped Late Bug If you’ve attended any of the main Volkswagen Events in the UK over the last couple of years, you’re bound to familiar with this late bug. Taking home a considerable amount of trophys from all over the country, it’s safe to say Alex has nailed the showcar formula. Throughout recent […]
Lyndon’s 1956 BeetleLimebug-Equiped Oval Well known in the Aircooled scene for his Volksworld featured Cal-Look ‘Fubar’, Lyndon is no stranger to exhaustive restorations. Using some of our suspension parts on his build (Beam, Spindles, etc), we were once again contacted to help with his latest project. Starting life in 1956 as a Jungle Green Oval, […]
LIMEBUG CASTOR-ADJUSTABLE TYPE 3 CONVERSION BEAMType 3 drivability and ride with Type 1 components Limebug Castor Adjustable Type 3 Beam Lets start this seciton with a deep dive into the controversial world of type 3 conversion beams. Why do any of this and change my Type 3 Beam? The simplest word to start this […]
Limebug Revolution Rear Air Ride – Installation Guide The Ultimate VW Beetle / Ghia and Type 3 Rear Air Ride System Limebug – Revolution Rear Air Ride Kit – Install Guide Limebug – Revolution Rear Air Ride Kit – Install Guide Trekker / Thing Rear Air Ride Kit View product Beetle / Karmann Ghia […]
FULLY ASSEMBLED BEAMS: CHOOSING YOUR SETUPBuilding your custom beam With lots of different options available in our Fully Assembled Beamlistings, you’re able to spec the perfect front axle, to work with the visual/handling requirements of your build. This illustrated guide will walk you through the steps and choices to make with our detailed and […]
Custom finishes/Add-ons are now available on a selection of Limebug-made parts… Wanting to go the extra mile on your build? Whether it’s a custom finish/centre cap for your Split Rims, or glossy Suspension Parts to make the floorpan of your car extra clean, we’re here to help… Feel free to browse some of our completed […]
Assembly of Three Piece Wheels / Split Rims The Basics A Three Piece Wheel / Split rim consists of an Outer Lip (or Outer Rim), Barrel (or Inner Rim) and the wheel centre itself. There are a number of rim bolts which seat on the wheel centre, go through the whole assembly, and are […]
123 Ignition Distributor Installation GuidesBluetooth, USB and Vac/ Non-Vacuum Operation and Install Documents 123 Ignition Guide – Tune BluetoothPDF Guide 123 Ignition Guide – Tune USBPDF Guide 123 Ignition Guide – BluetoothPDF Guide 123 Distributor (Bluetooth) Programmable Ignition View product 123 Distributor (USB) Programmable Ignition View product 123 Distributor (Vac) Premium Ignition View product […]
Additional lowering modifications on IRS Models with the “Revolution” Cantilever rear air ride kit fitted, achievable through the following guide: STEP 1 – Modified Subframe Horns This involves removing the outer skin of the pressing and replating using heavy gauge steel. As you can see in the picture the outer skin has been removed and moved […]
Limebug Ultrarm Pitman Steering ArmThe Steering Rate and Steering Lock solution for Narrowed Beams Limebug Ultrarm, the solution to poor steering lock, uneven steering and fouling shocks / dampers on narrowed beams. The Problem The ackermann angle, when a beam is stock width is configured so the inner wheel, when in a corner will turn […]
3P / 3H Airlift Second Compressor Loom Installation Guide Diagram Please see downloadable PDF for the 3P / 3H Airlift Second Compressor Loom Installation Guide Diagram below: The second compressor loom is available to purchase here This loom can be installed with our Manual Air Management Systems and also Airlift V2, for this diagram […]
BlackBugz’ 1957 BeetleLimebug-Equiped Oval Bug Over in Norway, a long-time customer of ours @vw_blackbugz has built a very special Oval. Originally buying his Air Kit back in 2018, TT has slowly upgraded his system to match modern designs. Most recently, the previous Monroe Air Shocks have been updated to our MOA430 Design. This provides the […]
Aircooled VW Through Rod Installation Guide Through rods are a direct replacement for the torsion leaf stack in the front beam / axle of an Aircooled VW. The through rods allow the trailing arms to free float up and down so that the air shocks can independantly manage the left and right hand sides of […]
Wiring diagram to cover 2 Way Tankless Air Ride Management Systems using Electric Paddle Switches and no tank For more information on the kit or to purchase click here 2 Way Tankless Air Ride Management Wiring Diagram Pneumatic Layout for T Pieces / Airline behind the Gauges / Switches:
Skid Plates? View the full range of Limebug skid plates, compatibility and function. The Limebug skid plate is a fantastic addition to any Beetle or Ghia. Compatible with either Link Pin or Ball Joint chassis, they provide great protection to the frame head and underside of your vehicle by deflecting objects/debris away from the undercarriage. […]
