Description

1966-79 Beetle / Ghia Ball Joint 4″ Narrowed Front Lowering Kit

Classic Aircooled VW Front Lowering Kits parts by Limebug

Limebug lowering kits contain everything you need to professionally lower the front of your Volkswagen with all bolt on parts, and simple installation.

Features:

– Limebug T1 1966-1979 Narrowed Ball Joint Beam:
– Limebug T1 Ball Joint Beam is manufactured in the UK and are the industry standard in quality and finish.
– Each beam is hand finished so please understand there may be upto a 2 week lead time on production. If this is an issue get in touch prior to ordering to ensure we can meet your build timescales.
– CDS Mech grade tubing, 8mm lasercut end-plates, CNC Body mounts & shock mounts, Dog Leg Shock Tower support. Unique Grease cavity system,– Steering Stop
– High quality delrin Bushes,grease fittings, steering damper mount, supplied in raw finish or powdercoated.

2x T1 1966-79 Beetle Front Ball Joint Lowered Gas Shock Absorber (237.5-368mm)

Aircooled VW Gas Charged Ultra High Performance Dampers

Shock Absorber for Lowered T1 1966-79 Beetle Front Ball Joint Models (Plus listed Models in Compability)

Each Damper is individually hand built to the highest quality in the industry. All Shocks are powder coated ensuring great cosmetic looks and excellent corrosion resistance.

This Ultra High Performance Progressive Dampers are made for the following applications:

Model: DT Progressive Dampers
Type: Gas
Style: Stud (Upper), Eyelet (Lower)
Stroke: 237.5mm-368mm
Sleeve Material/ Colour: Black W/Red Urethane

Compatible with:
–T1 Beetle (1966-79)
-T3 Ghia (1961-74)
-T34 Razor Edge (1961-74)
-T3 (All Variations) (1961-73)

T1 1966-79 Beetle / Ghia Ball Joint 2.5″ Dropped Spindles

Aircooled VW front suspension spindles / steering knuckle components

A smoother ride for ball joint front ends. These Dropped Spindles are manufactured from all new castings and feature Chromoly axles. Stronger and narrower than welded spindles! Dropped Spindles maintain factory steering geometry and you can use stock length shocks. Your VW will handle and ride better with a set of Dropped Spindles.

Note: Ball Joint Dropped Spindles drop your ride a full 2 1/2″ and extend the tires out 1/4″ on either side.

Details:

– CNC Machined from New Castings!
– Maintains Factory Steering Geometry
– Improves ride & handling
– Full 2 1/2″ Drop
– Chromoly Axles
– Stronger than Welded Spindles
– Narrower than Welded Spindles

Works with:
– Standard Length Shocks
– Standard VW bearings and seals
– 68-later uses stock bearings (1966-67 models will require a new bearing kit also to convert to the 1968-79 T1 Bearing Kit)
– 69-later tie rod ends (M12)
– Add 1/4″ Track Width Per Side

T1 Beetle Ghia RHD / LHD up to 4″ Narrowed Track / Tie Rods:

Professionally Engineering Track Rods from Limebug for all Aircooled VW’s stock width or narrowed.

High grade CDS turned seamless tubing is the foundation to building up our through rods, twinned with optional OE quality track rod ends and a hard wearing durable powder coat, this is the only sensible way to narrow your VW Beetle / Ghia.

We also produce these track rods in a stock width, meaning when the track rod end wears out you are not stuck with having to throw away the long rod as factory ends are crimped into place.

These feature, German Quality Track Rod Ends, and UK manufactured Track Rods. All Rods are made to our Width guides, and suited to LHD or RHD Appropriately.

If you have a special requirement or excessively narrowed vehicle we can accommodate this, at additional timescale.

Options:
-Track Width upto 4″ Narrowed Available. All track rods feature adjustment slots for easy tracking alignment.
-Hardware includes 2x LH and 2x RH threaded pinch nuts for security when fitted.
-All Track rods are supplied with a Steering damper eyelet as standard.
-M10 or M12 Stud Sizes available in all four configurations.

T1 RHD / LHD up to 4″ Narrowed Track / Tie Rods:
These feature, German Quality Track Rod Ends, and UK manufactured Track Rods. All Rods are made to our Width guides, and suited to LHD or RHD Appropriately.
Options of Track Width upto 4″ Narrowed Available. All track rods feature adjustment slots for easy tracking alignment,
Also all track rods come with 2x LH and 2x RH Thread Pinch nuts for security when fitted.
All Track rods are suppiled with a Steering Damper Eyelet as Standard.
M10 or M12 Stud Sizes available in all four configurations

T1 1966-79 Beetle / Ghia Spindle Caster / Camber Adjustment Nut (Pair)

Aircooled VW front suspension components

Long travel caster / camber nuts for all Ball Joint model T1 Beetle / Ghia Models. Utilises an eccentric hole which can be rotated to achieved desired caster / camber. This part has the hole slightly further over to give additional effect

Premium quality product, and a must have for any lowered VW.

Details:
– Weight: 0.121Kg
– EAN13 Code: 5710412001605
– OE Code: AC401380
– OE Ref 1:
– OE Ref 2:
– Brand: Limebug

SKU: 030050003
