T1 1966-79 Beetle / Karmann Ghia Ball Joint 6″ Narrowed Complete Front Air Ride Kit with Gen II Jawbreaker Beam

Classic Aircooled VW Front Air Ride Kits parts by Limebug

Narrowed front beams have become one of our foundation and most popular lines. Our Titan (Static) and Jawbreaker (Air Ride) Series beams have paved the way for simple installation and feature rich design. The recipe has remained largely unchanged since conception with narrowed beams becoming the standard for any vehicle upgrading to larger wheels/ disk brakes and getting the front of the vehicle down.

Proudly presenting the Second Generation modular beam brings a new freedom to evolve and sustain.

You Spoke, We Listened

The Aircooled VW pan has long been the go to platform for not just custom builds of standard platform VW based vehicles, but kit cars, recreations, tributes, beach buggy's and all manner of automotive. The platform is one of the most versatile and long standing seen in any car manufacturers history, and with this comes the requirement for constant change and easily customisable front axles.

Since Limebug's conception we have followed the change in trends through the ages and so many custom touches are added to each individuals beam for totally unique reasons the concept of a Modular Axle came to fruition.

Modular Beam, What does that mean?

We has created the first of its kind, modular beam, by retaining a universal central core, the beam's end plates give options to replace and change as the styling of the vehicle evolves. this means that while the individual decisions of, design / style and application dictate the beams final form, it is infinitely up-gradable and serviceable.

The System, How does it Work?

Below is an illustration of a few combinations of the Gen-II modular beam…

Choose your end plates to suit your current build, and then have the flexibility to change them in the future.

What does this mean for my build? Installation / Maintaining?

Gen-II offers the expansion room to change and adapt your build with time as well as maintain and upgrade your single beam unit with minimal upkeep costs. All spares available through our website.

Installation has been simplified another step, the beams unique design also has added benefits when fitting or mocking up. Install the centre module first, then offer up the towers after to ensure perfect inner wings every time as well as not requiring ramps or a second pair of hands for installation or removal.

Limebug front air systems use the best air shocks available in the business, our UK built through rods with roller ends and unique locator accompanied by the highest quality air taps and fixings available.

If Ball Joint we recommend installing long travel ball joints to allow for maximum drop.

Bolt-on Lower Shock Relocators are included for Link Pin kits.

Grease seals are also included with kits for both Link Pin and Ball Joint platforms

Limebug's British 'Titan Engineering' department have been developing the most functional, innovative and beautiful parts in the scene to date. We have just introduced our Bug & Bus air ride ranges. Each kit is designed by certified and accredited engineers here at Limebug, before being tested by us personally to ensure ease of fitment and function.

These air systems come with our online video tutorial for installation and operation, as well as a manual and guide to installation. Our video includes an explanation of upgrades, year differences. Neat tricks to look out for along the way, and other great ways to give you VW the look you've dreamt of without the nightmares.

Titan Through Rods Explained

T1 RHD / LHD 4" Narrowed Track / Tie Rods:

Professionally Engineering Track Rods from Limebug for all Aircooled VW's stock width or narrowed.

High grade CDS turned seamless tubing is the foundation to building up our through rods, twinned with optional OE quality track rod ends and a hard wearing durable powder coat, this is the only sensible way to narrow your VW Beetle / Ghia.

We also produce these track rods in a stock width, meaning when the track rod end wears out you are not stuck with having to throw away the long rod as factory ends are crimped into place.

These feature, German Quality Track Rod Ends, and UK manufactured Track Rods. All Rods are made to our Width guides, and suited to LHD or RHD Appropriately.

If you have a special requirement or excessively narrowed vehicle we can accommodate this, at additional timescale.

Options:
-Track Width upto 6" Narrowed Available. All track rods feature adjustment slots for easy tracking alignment.
-Hardware includes 2x LH and 2x RH threaded pinch nuts for security when fitted.
-All Track rods are supplied with a Steering damper eyelet as standard.
-M10 or M12 Stud Sizes available in all four configurations.

Titan Engineering T1 Beetle / Ghia "Mine Sweeper" Skid Plate

Compatible with all Titan, Jawbreaker and Original Aircooled VW Beams

Features a steep ramped front edge to deflect the road and debris away from your beam when running extra low. Protects your adjuster unit as well as still allowing access through the front of skid plate.

Minesweeper plates are provided raw unless otherwise stated. Comes with two extended frame head bolts and washers which is all that is required for fitting.

The Minesweeper features a totally unique pellet system where interchangeable bolts can be fitted through the skid plate. As standard we provide each skidplate with stainless pellets. These give a bright Yellow Short Spark Trail. We offer pellets to give your choice of White, Yellow, Short and Long Sparks with your skid plate. Once worn through, simply remove the skidplate and remove the old pellets, then refit the new ones. Also it is possible to mix and match to create multiple coloured spark trails.

Limebug's British 'Titan Engineering' department have been developing the most functional, innovative and beautiful parts in the scene to date. We have just introduced our Bug & Bus air ride ranges. Each kit is designed by certified and accredited engineers here at Limebug, before being tested by us personally to ensure ease of fitment and function.

These air systems come with our online video tutorial for installation and operation, as well as a manual and guide to installation. Our video includes an explanation of upgrades, year differences. Neat tricks to look out for along the way, and other great ways to give you VW the look you've dreamt of without the nightmares.

Titan Through Rods Explained

T1 RHD / LHD 4" Narrowed Track / Tie Rods:

Professionally Engineering Track Rods from Limebug for all Aircooled VW's stock width or narrowed.

High grade CDS turned seamless tubing is the foundation to building up our through rods, twinned with optional OE quality track rod ends and a hard wearing durable powder coat, this is the only sensible way to narrow your VW Beetle / Ghia.

We also produce these track rods in a stock width, meaning when the track rod end wears out you are not stuck with having to throw away the long rod as factory ends are crimped into place.

These feature, German Quality Track Rod Ends, and UK manufactured Track Rods. All Rods are made to our Width guides, and suited to LHD or RHD Appropriately.

If you have a special requirement or excessively narrowed vehicle we can accommodate this, at additional timescale.

Options:
-Track Width upto 6" Narrowed Available. All track rods feature adjustment slots for easy tracking alignment.
-Hardware includes 2x LH and 2x RH threaded pinch nuts for security when fitted.
-All Track rods are supplied with a Steering damper eyelet as standard.
-M10 or M12 Stud Sizes available in all four configurations.

Titan Engineering T1 Beetle / Ghia "Mine Sweeper" Skid Plate

Compatible with all Titan, Jawbreaker and Original Aircooled VW Beams

Features a steep ramped front edge to deflect the road and debris away from your beam when running extra low. Protects your adjuster unit as well as still allowing access through the front of skid plate.

Minesweeper plates are provided raw unless otherwise stated. Comes with two extended frame head bolts and washers which is all that is required for fitting.

The Minesweeper features a totally unique pellet system where interchangeable bolts can be fitted through the skid plate. As standard we provide each skidplate with stainless pellets. These give a bright Yellow Short Spark Trail. We offer pellets to give your choice of White, Yellow, Short and Long Sparks with your skid plate. Once worn through, simply remove the skidplate and remove the old pellets, then refit the new ones. Also it is possible to mix and match to create multiple coloured spark trails.

SKU: 030010342
