Performance Aircooled VW Camshafts Explained / Complete Data Sheet
Camshafts & Accessories
Scat Camshafts have these great features:
- Race Proven Camshaft Profiles Designed For All Types Of Engine Applications
- All specifications are at the valve using a .050″ checking clearance
- Consistent lobe hardness all the way to the core center (Chilled Cast)
- Material is compatible and uniform with 20018 lifters (55-60 RC)
- Tough enough to stand up to high valve spring pressures
- Larger lobe heel for smoother rotation and strength
- Reinforced and clearanced were it counts
- All cams are stroke relieved or clearenced for longer stroke camshafts
Pro-Comp & Drag Hardcore Early Type 1 Bolt-on Gear Racing Camshafts
Street and Off-Road
| Scat Part # | Grind | Lift @ Cam Lobe | Adv Dur | Dur @ .050″ | Buy |
|---|---|---|---|---|---|
| 20003 | C20 | .320″ | 277 | 234 | Buy Now! |
| 20004 | C25 | .350″ | 272 | 234 | Buy Now! |
| 20005 | C35 | .381″ | 285 | 246 | Buy Now! |
| 20006 | C45 | .390″ | 298 | 262 | Buy Now! |
Competition Camshafts
| Scat Part # | Grind | Lift @ Cam Lobe | Adv Dur | Dur @ .050″ | Buy |
|---|---|---|---|---|---|
| 20121C | C95 | .416″ | 294 | 262 | Buy Now! |
| 20007C | C55 | .410″ | 310 | 271 | Buy Now! |
| 20008C | C65 | .413″ | 309 | 274 | Buy Now! |
Drag Racer Camshafts
| Scat Part # | Grind | Lift @ Cam Lobe | Adv Dur | Dur @ .050″ | Buy |
|---|---|---|---|---|---|
| 20169C | C89 | .410″ | 318 | 274 | Buy Now! |
| 20095C | C85 | .409″ | 324 | 287 | Buy Now! |
| 20009C | C75 | .425″ | 322 | 294 | Buy Now! |
